APT-GB connAV

€ 2.695,00

Discover the latest innovation in teleprompter video technology: the SMV2 Teleprompter.Video series, now available in a slim 1U rack unit. This versatile unit is designed to meet all your video and audio distribution needs for teleprompters and can encode and decode multiple video formats straight out of the box. Thanks to the same advanced software and hardware as the renowned SMV224 and SMV212 products, seamless integration into your setup is guaranteed.

Setting up and using features is child’s play thanks to the intuitive web browser interface. Easily export settings for backup or when switching between devices, ensuring your important configurations are preserved. What’s more, you’ll stay informed thanks to the OLED screen, which displays essential information such as IP address, input and resource usage.

With 3-pin XLR connectors, audio signals are seamlessly integrated into your video streams, simplifying connection to audio systems. And with the Neutrik powerCON TRUE1 input and output, powering and connecting signal sources on stage is a piece of cake.

This unit is designed for the harsh conditions of touring and operates worldwide, with voltages ranging from 90–260 V and frequencies of 50/60 Hz. Whether you’re in New York or Tokyo, you can count on consistent performance.

Experience unrivalled signal conversion and routing capabilities with support for network video, NDI, HDMI and SDI inputs and outputs. Easily play back and record to an internal SSD or external USB stick.

Maximise flexibility with support for resolutions up to 4K30 and 3G SDI up to 1080P60. Integrate seamlessly with common network video protocols such as RTSP, RTMP, HTTP, HLS, UDP, Unicast, Multicast, ONVIF, SRT and NDI®|HX.

Equipped with a built-in 1 Gbps 4-port switch and Wi-Fi 6, networking is seamless and efficient. Take advantage of the built-in web interface to make configuration changes and enhance support with Tailscale’s secure remote access service (internet access and a free user account required for activation).

Take your teleprompter video setup to the next level with the SMV2 Teleprompter.Video series – the pinnacle of performance, reliability and ease of use.

All our listed prices are net prices! (excluding delivery costs and including 21% VAT.)

Terms and Conditions:

We do not offer any right of return! Our products are made to measure especially for you! You have no right whatsoever to request a refund via your credit card and/or PayPal account. For credit card and PayPal payments, you will be charged a 3.5% transaction fee

Production time is 10 working days, depending on the type of monitor, and delivery time (usually 14 days after ordering), provided we have received your payment into our bank account. We will keep you informed of the current delivery status.
By placing an order, you fully agree to our delivery terms and conditions.

SKU: ConnAV-2 Categories: , ,

Description

Additional Information connAV

Weight 3 kg
Maximum Resolution 4K 30fps
Connectors 4 x etherCON, 2 x BNC SDI, 3 x HDMI, 1 x powerCON TRUE1 (top, rear input and output), 1 x powerCON TRUE1 (front)
Power 90 V – 260 V AC, 50–60 Hz, 2 A
Size (H x W x D) 44, 482, 220 mm – 1U Rack
Construction 3 mm steel
Finish Satin black powder coating
Support 4 rubber feet on the base
HDMI Input HDMI 1.4 supports resolutions up to 4K at 30 frames per second.
SDI Input 3G-SDI, up to 1080P60
Supported Input Resolutions 4K30 1080p 720p 1080i 720i 1600×1200 1440×900 1366×768 1280×1024 1024×768 800×600 640×480
Encoding Format H.264, H.265, MJPEG/JPEG Main and Baseline Profiles
Decoding Format H264, H265, MJPEG
Frame Rate 1-60 fps Adjustable
Maximum Bit Rate 40 Mbit/s
Rate Control CBR/VBR/AVBR/FIXQP/QPMAP
Network Transfer Protocol RTSP, RTMP, HTTP, HLS, UDP, Unicast, Multicast, ONVIF, SRT, NDI®, HX
Playback/Recording Storage FAT32-formatted storage, maximum 32 GB, 256 GB internal SSD with multiple partitions selectable via the web interface.
Network Interface 10/100/1000M RJ45 EtherCON input and output, Wi-Fi 2.4 GHz
User Interface Web configuration, firmware update, network settings, password management, uploading watermark logos/images

Additional information

Weight 10 kg
Dimensions 48,2 × 22,2 × 4,4 cm
